Ultra-Cor

The strongest corrugated steel plate available • Handles extreme loadings • Spans up to 30 m (98′) • Corrugation profile of 500 mm (20″) pitch × 237 mm (9.5″) depth • Available in: Box Culverts; and Standard, Low, Medium, or High Profile Arches • Easy to ship and install for remote locations • Long-lasting and virtually maintenance-free • Bottomless designs are more environmentally-friendly • Available with a variety of footing and headwall/wingwall options • Available with Best•Kote Polymer Coating • Manufactured in accordance with CHBDC, AASHTO and ASTM design requirements

Recommended For:
Structural Plate Arches and Bridges, Grade Separations, Road or Rail Underpasses, Stream Crossings, Box Culverts, Heavy Haul Road Arches, Stockpile Tunnels, Portals and Canopies

Super-Cor

  • Handles extreme loadings
  • Spans can exceed 25 m (82′)
  • Corrugation profile of 381 mm (15″) pitch x 140 mm (5.5″) depth
  • Available in: Box Culverts; Standard, Low, Medium or High Profile Arches; Rounds; and Ellipses
  • Easy to ship and install for remote locations
  • Long-lasting and virtually maintenance-free
  • Bottomless designs are more environmentally-friendly
  • Available with a variety of footing and headwall/wingwall options
  • Available with Best•Kote Polymer Coating
  • Can reline older structures
  • Manufactured in accordance with CHBDC, AASHTO and ASTM design requirements

Recommended For:
Structural Plate Arches and Bridges, Grade Separations, Road or Rail Underpasses, Stream Crossings, Box Culverts, Heavy Haul Road Arches, Stockpile Tunnels, Storage Structures, Portals and Canopies

THE EDGE Four-Flange Structural Liner

  • 10 times stiffer and 5 times stronger than traditional steel liner plate
  • Handles extreme loadings
  • Accelerated assembly, easier fitting of plates
  • Smaller crews needed, lower installed costs
  • Added safety, structures can be built from one side
  • Easy to ship and install for remote locations
  • Long-lasting and virtually maintenance-free
  • Spans can exceed 25 m (82′)
  • Corrugation profile of 381 mm (15″) pitch and 140 mm (5.5″) depth
  • Available in traditional and custom shapes
  • Available uncoated or with hot-dip galvanized or Best•Kote Polymer coatings
  • Suitable for field-applied coatings
  • Grout coupling sizes and placement to suit site conditions
  • Custom fittings
  • Gaskets allow for leak-resistant structures
  • Lower cost tank storage option
  • Structures can be dismantled and removed

Recommended For:
Mine Shafts, Vent Raises, Escape-Way, Portals and Canopies„„, Ground Support Structures, „„Relining of Existing Structures, Road or Rail Underpasses„, Heavy Haul Road Arches, Stockpile Tunnels, Storage Structures, Protection Structures
